- Model： GLA U series
GLA U series
Details
| Basic Load Ratings | Life coefficients | |||||||||||||||
| Designation | Mass | Dimensions | Dynamic load | Limiting loads | ||||||||||||
| De | dB | Di | Y | A | B | Cw | Cor | Coa | Pa/Pr≤0.37 | Pa/Pr＞0.37 | ||||||
| UBM | radial | axial | X | Y | X | Y | ||||||||||
| Kg | mm | kN | ||||||||||||||
| GLA 17.06 | 0.01 | 17 | 6 | 5 | 10.5 | 7.0 | 8 | 1.5 | 0.84 | 0.35 | 1 | 1.37 | 0.5 | 2.73 | ||
| GLA 24.06 | 0.02 | 24 | 6 | 8 | 14 | 11.0 | 11 | 4.2 | 2.3 | 1 | 1 | 1.37 | 0.5 | 2.73 | ||
| GLA 35.10 | 0.08 | 35 | 10 | 12 | 20.65 | 15.9 | 15.9 | 7.9 | 5.1 | 1.5 | 1 | 1.67 | 0.5 | 3.03 | ||
| GLA 35.12 | 0.08 | 35 | 12 | 12 | 21.75 | 15.9 | 15.9 | 7.8 | 5 | 1.4 | 1 | 2.47 | 0.5 | 3.83 | ||
| GLA 42.10 | 0.1 | 42 | 10 | 12 | 24 | 19.0 | 19 | 12 | 7.1 | 2.1 | 1 | 1.17 | 0.5 | 2.53 | ||
| GLA 47.10 | 0.17 | 47 | 10 | 15 | 26.65 | 19.0 | 19 | 15.4 | 9.2 | 3.3 | 1 | 0.97 | 0.5 | 2.33 | ||
| GLA 52.16 | 0.23 | 52 | 16 | 20 | 31.5 | 20.6 | 22.6 | 19.3 | 10.5 | 4 | 1 | 2.17 | 0.5 | 3.53 | ||
