- 产品型号：FK系列
FK系列
产品详情：
| Basic Load Ratings | Limit loads | |||||||||||||
| Designation | Mass | Dimensions | Dynamic load | |||||||||||
| De | d | A | B | C | R | F | d2 | M | Cw | Fr | ||||
| UBM | radial | |||||||||||||
| Kg | mm | kN | kN | |||||||||||
| FK 52C | 0.5 | 52 | 15 | 35 | 42 | 29 | 800 | 25 | 2.5 | 30 | 42.1 | 11.9 | ||
| FK 62C | 0.6 | 62 | 20 | 37 | 45 | 29 | 800 | 29 | 3 | 35 | 47.75 | 22.1 | ||
| FK 72C | 1.2 | 72 | 25 | 45 | 56 | 33 | 1200 | 37 | 4 | 44 | 67.45 | 31.3 | ||
| FK 90C | 2.3 | 90 | 28 | 53 56 | 64 | 45 | 1200 | 42 | 4 | 49 | 118 | 43.7 | ||
| FK 110C | 3.9 | 110 | 35 | 60 63 | 72 | 48 | 1200 | 52 | 4 | 59 | 185 | 55.6 | ||
